300 kg
Load capacity with 4 wheels
Modular pipe systems
Attachments
Modular pipe systems
Attachments
The Genius 2 module from wheel.me transforms racks, trolleys, pallets and more into fully-fledged autonomous mobile robots (AMR).
Safety certification (Level D)
Dynamic obstacle detection
Unlimited flexibility
Load capacity with 4 wheels
for a 4-wheel system (plus charging station (1000€) and software (540€/year))
Flexibility in terms of basic dimensions, superstructures and intended use
Individual applications, such as the transportation of racks, pallets, pallet cages and more, can be implemented quickly and easily.
A comparison of autonomous wheels, AMR and AGVs. In this e-book we answer the following questions:
A comparison of autonomous wheels, AMR and AGVs.
Simple implementation of use cases for the automation of intralogistics
Low downtimes thanks to plug-and-play principle for easy maintenance
Freely scalable dimensions of the robot platform for every application
Automatic loading of the units via contact surfaces on the floor
Reliable & secure communication of the robots via WiFi & 5G
Our round pipes and square profiles made of steel and aluminum offer the perfect way to implement your application - retrofitting of existing equipment is also possible.
Automated transport of existing or new racking systems
Automated transport of pallets with square base frames
Automated provision of material in production & logistics for a seamless material flow
4 Wheels (Genius 2) | Other AMR | Manual transport | ||
---|---|---|---|---|
Prices | ||||
One-time costs | <19.000 Euro |
> 30.000 Euro |
350 Euro |
|
Running costs (per year) | 540 Euro |
depending on provider |
~ 30.000 Euro |
|
Premium service (per year, optional) | 900 Euro |
- |
- |
|
Features | ||||
Simple implementation | ||||
Easy maintenance | ||||
Flexibility | Very high |
Medium |
Low |
|
Load capacity | 300 kg |
depending on provider |
up to 1.500 kg |
|
Dynamic obstacle detection | ||||
Lane-free, autonomous navigation |
With the wheel.me app, you can manage the tasks that your Genius 2 systems perform for you - clearly and simply.
Intuitive user interface
Automatic mapping
Real-time management
This allows you to maintain control of your robot fleet and your material flow in production and logistics at all times.
They can be controlled from any device and location (web app in the cloud).
General data | |
---|---|
Type |
Autonomous wheel, available in sets of 4 and 8 |
Drive system |
Mechanical wheel with PU rollers |
Movement |
Omnidirectional |
Color |
RAL 9005, deep black |
Housing material |
PC-ABS |
General data
Type: Autonomous wheel, available in sets of 4 and 8
Drive system: Mechanical wheel with PU rollers
Movement: Omnidirectional
Color: RAL 9005, deep black
Housing material: PC-ABS
Dimensions and load capacity | |
---|---|
Dimensions and weight (main wheel) |
193 x 269 x 134 mm / 4.6 kg (excl. battery) |
Dimensions and weight (supporter) |
193 x 186 x 134 mm / 3.9 kg (excl. battery) |
Weight of the battery |
0,8 kg |
Minimum dimensions of the AMR |
495 x 700 mm |
Load capacity per wheel (max.) |
75 kg |
Load capacity of a 4-wheel system (max.) |
300 kg |
Dimensions and load capacity
Dimensions and weight (main wheel): 193 x 269 x 134 mm / 4.6 kg (excl. battery)
Dimensions and weight (supporter): 193 x 186 x 134 mm / 3.9 kg (excl. battery)
Weight of the battery: 0.8 kg
Minimum dimension of the AMR: 495 x 700 mm
Load capacity per wheel (max.): 100 kg
Load capacity of a 4-wheel system (max.): 400 kg
Load capacity of a 8-wheel system (max.): 800 kg
Safety and certification | |
---|---|
Safety standard (EU) |
CE, SIL-2, performance level D |
Safety standard (US) |
ETL, FCC |
Safety zones |
3-zone safety (speed-dependent) |
Safety and certification
Safety standard (EU): CE, SIL-2, performance level D
Safety standard (US): ETL, FCC
Safety zones: 3- zone safety (speed-dependent)
Safety and certification | |
---|---|
Safety standard (EU) |
CE, SIL-2, performance level D |
Safety standard (US) |
ETL, FCC |
Safety zones |
3-zone safety (depending on speed) |
Navigation and environment | |
---|---|
Navigation speed |
0.8 m/s (max.) |
Rotation diameter |
Zero point rotation |
Area of application |
Indoor |
Ambient temperature (in operation) |
5 to 40 °C |
Humidity |
50% relative humidity at 40 °C |
Protection against ingress of water and dust |
IP20 |
Minimum ambient lighting brightness |
40 lux |
Floor conditions |
Dry, no grease / oil / dirt |
Navigation and environment
Navigation speed: 0.8 m/s (max.)
Rotation diameter: Zero point rotation
Area of application: Indoor
Ambient temperature (in operation): 5 to 40 °C
Humidity: 50% relative humidity at 40 °C
Protection against ingress of water and dust: IP20
Minimum ambient lighting brightness: 40 lux
Floor conditions: Dry, no grease / oil / dirt
Navigation and environment | |
---|---|
Speed |
0,8 m/s (max.) |
Turning diameter |
Zero-point rotation |
Area of application |
Indoor |
Environmental temperature (during operation) |
|
Humidity |
50% relative humidity at 40 °C |
Protection against water and dust entry |
IP20 |
Minimum brightness of the ambient lighting |
40 Lux |
Floor conditions |
Dry, no grease / oil / dirt |
Battery and charging | |
---|---|
Type of battery |
Lithium-ion 21700 |
Nominal voltage of the battery |
14,4 G |
Positioning of the charger |
Floor and surface mounting |
Type of load |
Autonomous, via contact surfaces on the floor |
Battery runtime |
5,5 h |
Charging duration (from 10-90%) |
1 h |
Battery and charing
Type of battery: Lithium-ion 21700
Nominal voltage of the battery: 14,4 G
Positioning of the charger: Floor and surface mounting
Type of load: Autonomous, via contact surfaces on the floor
Battery runtime: 5.5 h
Charging duration (from 10-90%): 1 h
Communication and sensors | |
---|---|
Wireless communication |
WLAN 2.4, 5 GHz, 802.11ac, internal and external antennas |
Wired communication |
CAN / Ethernet |
LiDAR |
4 pieces / set |
LiDAR-FoV |
2 x 360° |
Camera |
1x Intel RealSense (per set), 1x ultra-wide-angle lens (per set) |
Communication and sensors
Wireless communication: WLAN 2.4, 5 GHz, 802.11ac, internal and external antennas
Wired communication: CAN / Ethernet
LiDAR: 4 pieces / set
LiDAR-FoV: 2 x 360°
Camera: 1 x Intel RealSense (per set), 1 x ultra-wide-angle lens (per set)
Communication and sensor technology | |
---|---|
Wireless communication |
WLAN 2.4, 5 GHz, 802.11ac, internal and external antennas |
Wired communication |
CAN / Ethernet |
LiDAR |
4 pieces / set |
LiDAR-FoV |
2 x 360° |
Camera |
1x Intel RealSense (per set), 1x ultra-wide-angle lens (per set) |
